Captiva Designs Extra Large Charcoal BBQ Grill Review

Updated: July 31, 2026

This Captiva Designs Extra Large Charcoal BBQ Grill review is based on the manufacturer’s manual, current product information, and buyer-focused feature analysis. I have not claimed hands-on testing of this grill. Prices and availability can change.

Is the Captiva Designs Extra Large Charcoal BBQ Grill Worth Buying?

Yes—for the right backyard cook. This Captiva is appealing when you regularly need more width than a kettle grill gives you and want to cook at two heat levels at once. One charcoal tray can be raised closer to the food for direct grilling while the other sits lower for gentler heat. You can also load charcoal on only one side and use the opposite side as an indirect finishing zone.

The important limitation is that the headline “794 square inches” includes a 289-square-inch upper warming rack. The main cooking grate is 505 square inches. That is still useful room, but buyers should compare grills by their primary grate—not by a total that combines two surfaces with different jobs.

This is also a large steel cart, not a set-it-and-forget-it smoker. The adjustable trays, air vents, chimney, and lid thermometer give you several ways to influence the fire, but the cook still controls temperature by managing charcoal quantity, placement, airflow, and time. If your main goal is long unattended smoking, a dedicated smoker or gravity-fed charcoal cooker will be easier to manage.

What Are the Key Facts and Specifications?

The specifications above come from the current product listing and the Captiva Designs E02GR005 use and care guide. One reason to include the model number is that retailer titles and measurements sometimes vary slightly. Match GR005 or E02GR005 before assuming a cover or replacement part will fit.

How Do the Two Adjustable Charcoal Trays Change the Cooking?

The two-tray arrangement is the main reason to choose this Captiva instead of an ordinary single-basin charcoal cart. Each side has its own lifting control. Raising a tray moves the coals closer to the food; lowering it increases the distance between the coals and grate. That does not create automatic temperature control, but it gives you a useful adjustment without having to move hot charcoal during the cook.

Direct and indirect cooking at the same time

For a two-zone meal, you could build a stronger fire on one side for browning burgers, steaks, or chops and keep a milder zone on the other for finishing thicker food. Another approach is to light charcoal on only one tray and leave the other tray empty. Food placed over the unlit side then cooks by indirect heat with the lid closed.

This flexibility is particularly helpful when several foods have different heat needs. Thin food can cook over the hotter section while thicker pieces finish away from the strongest heat. It also gives you a retreat when dripping fat causes flare-ups. The trays help establish those zones, but an instant-read thermometer is still the reliable way to determine when meat is done.

Front charcoal doors reduce unnecessary lid opening

Two front doors provide access to the charcoal area. That means you can tend or add fuel without removing the food and main cooking grates. Any opened door changes airflow and releases heat, so “less disturbance” should not be confused with “no temperature loss.” Still, front access is more convenient than lifting a loaded cooking grate just to reach the coals.

How Much Usable Cooking Space Does It Really Have?

The 505-square-inch primary grate is the number that should guide your buying decision. The 289-square-inch upper rack brings the advertised total to 794 square inches, but the two surfaces are not interchangeable. The upper rack sits farther from the charcoal and is better suited to cooked food, buns, vegetables that need gentler heat, or food you deliberately want away from the strongest fire.

Captiva markets the grill for larger gatherings, and the wide rectangular layout supports that purpose. However, a food-count promise such as “20 burgers” can be misleading because patties, steaks, chicken pieces, and safe spacing all vary. A better method is to measure the pans, rib racks, or food arrangement you normally use and compare them with a 505-square-inch primary surface.

The grill is approximately 63 inches wide with the side tables extended according to the current listing. Those tables add useful landing space for trays and tools, but they are also part of the footprint. They fold down for storage. Before buying, check both the cooking location and the width of the gate, shed door, or path used to move it.

Can the Captiva Designs Extra Large Grill Smoke Meat?

It can cook with indirect heat and wood smoke, but it is not a dedicated offset smoker. Put lit charcoal and a modest amount of smoking wood on one side, place the food on the unlit side, close the lid, and regulate the fire with the tray height and airflow. The chimney encourages heat and smoke to move through the covered cooking chamber.

What buyers should not assume is that the grill will automatically hold a particular smoking temperature for hours. The published design confirms adjustable vents, an adjustable chimney, and a lid gauge; it does not prove a universal 225°F hold time or overnight performance. Weather, charcoal type, fuel load, vent position, leakage, and how often the doors or lid are opened can all change the result.

The built-in lid thermometer is useful for watching general chamber movement, but it does not measure the temperature at the exact location of the meat. For ribs, pork shoulder, or other longer cooks, use a separate grate-level probe and a meat probe. Start with small vent changes, give the grill time to respond, and record the settings that work in your weather.

If smoking is your main reason for buying, compare this cart with a purpose-built option in my best barrel smokers guide. If grilling for a group is the main job and occasional indirect smoking is a bonus, the Captiva layout makes more sense.

What Should Buyers Know About the Build, Storage, and Cleanup?

Steel cart with enamel-coated cooking components

The current listing identifies a metal steel body, enamel grids and charcoal trays, plus a plated warming grate. That wording matters. It does not support calling the entire grill body porcelain enameled, “heavy gauge,” or rustproof. The manual tells owners to clean the grill after it has completely cooled, and the product listing recommends keeping it covered when not in use.

For longer life, keep water from sitting in the ash pan or bottom of the grill, empty cooled ash promptly, touch up exposed steel according to the manufacturer’s guidance, and use a fitted cover only after the grill is cool and dry. Charcoal ash can hold moisture against metal, so leaving a full ash pan in damp weather is a poor storage habit.

Assembly is a real part of the purchase

The Captiva manual lists an estimated assembly time of 30 minutes and says a wrench and Phillips screwdriver are required but not included. The illustrated procedure spans many steps and includes the cart, body panels, lid, chimney, tables, doors, lifting controls, trays, grates, ash pan, and accessories.

Treat the manufacturer’s 30-minute figure as an estimate, not a promise. Lay out the hardware, identify left and right parts before tightening, and consider having a second adult help stabilize larger pieces. After assembly, verify that the tray controls, doors, lid, wheels, vents, and chimney move correctly before lighting charcoal.

Ash removal is simpler than shoveling the firebox

A full-size ash pan sits beneath the charcoal area. Once the grill and ash are completely cold, the pan can be removed for disposal. The manual specifically warns against using water to extinguish charcoal and instructs owners to allow the grill to cool before cleaning. Dispose of ash in a suitable noncombustible container and follow local rules.

Clean cooled enamel parts with mild soap and water. Avoid aggressive cleaning that chips the coating. Inspect fasteners, tray controls, doors, and vents periodically. A large charcoal grill has more moving and exposed parts than a simple kettle, so routine checks are worthwhile.

What Are the Main Pros and Cons?

Who Should Buy This Grill—and Who Should Skip It?

Buy it if:

• You often cook for a family or backyard group and want a wide rectangular grate.
• You value separate left and right charcoal zones more than compact size.
• You cook mixed menus that benefit from a hot side and a gentler side.
• You want front fuel access, an ash pan, side tables, and storage in one cart.
• You mainly grill but would also like to try covered indirect cooking and basic smoking.

Skip it if:

• You have a narrow balcony, small patio, or limited covered storage.
• You need a grill that is easy to lift into a vehicle for regular tailgating.
• You want automatic control or long cooks with minimal fire management.
• You prefer the simplicity and fewer moving parts of a kettle grill.
• Your main goal is traditional offset smoking rather than grilling for a crowd.

Buyers comparing other wide charcoal carts should also read my MELLCOM 36-inch large charcoal grill review. Compare primary-grate size, fuel access, tray adjustment, total footprint, replacement-part support, and current delivered price—not just the largest number printed in a title.

Frequently Asked Questions

What is the actual cooking area of the Captiva Designs Extra Large Charcoal BBQ Grill?

Captiva lists 794 square inches in total: a 505-square-inch primary cooking grate and a 289-square-inch warming rack. Use 505 square inches when comparing the main grilling surface with another grill.

Are the two charcoal trays independently adjustable?

Yes. Each tray can be raised or lowered separately. This helps create a hotter side and a gentler side, although temperature still depends on charcoal quantity, placement, airflow, and weather.

Can you add charcoal without removing the food?

The grill has two front charcoal doors that provide access below the cooking grates. Open them carefully with heat-resistant gloves because the doors, handles, and nearby metal can become hot during use.

Does the Captiva GR005 have a built-in thermometer and vents?

Yes. The parts list and product documentation show a lid temperature gauge, two body air vents, and an adjustable chimney. For longer cooks, a separate grate-level probe gives a more useful reading near the food.

Can this grill be used as a smoker?

It can cook with indirect heat and smoking wood when charcoal is placed on one side and food on the other. It is not a dedicated offset or automatic smoker, so the cook must actively manage fuel, airflow, and temperature.

How difficult is the Captiva Extra Large charcoal grill to assemble?

Assembly is required. The manual estimates 30 minutes and calls for a wrench and Phillips screwdriver, neither of which is included. Because the grill is large and the instructions contain many assembly steps, allow extra time and consider a second adult for stabilizing larger sections.

How should the grill be protected from rust and weather?

Keep it covered and dry after it has completely cooled. Remove cooled ash, do not allow water to sit in the ash pan or body, and periodically inspect the coating and hardware. The product information identifies a steel body, so it should not be treated as weatherproof.

How much charcoal can the Captiva GR005 hold?

The official use and care guide states a maximum charcoal amount of 2.75 kilograms, which is about 6.1 pounds. Do not overfill the trays, and follow the lighting and safety instructions supplied with the grill.
